Double Head Convex & Mini Linear Color Doppler MLCCD-3.2







The Double Head Convex & Mini Linear Color Doppler MLCCD-3.2 offers great intell in the medical imaging arena. The double head MLCCD-3.2 has a frequency range from 3.5 – 14 MHz. Hence, it provides a depth range from 20 – 200 mm deep into the skin. Making it an eligible tool for many medical specialties.

To name a few; anesthesiology, Physiotherapy, cardiology rheumatology, podiatry … Thanks to the color Doppler feature the double head MLCCD-3.2 gives images of blood vessels that represent the speed and direction of blood flow through the vessel.

The Double head MLCCD-3.2 also, provides an overview of central venous access and Vascular (venous) access for pediatric resuscitation and other pediatric emergencies and Placement of femoral venous catheters and Placement of subclavian venous catheters and Placement of jugular venous catheters.

Besides, the wireless ultrasound scanner gains full software options to improve image quality, resolution, contrast, and artifact removal. Hence enhanced needle visualization for joint injections, nerve blocks, dry needling …

Moreover, the wireless ultrasound scanner MLCCD-3.2 mini linear array is built-in with a needle guide. Saving up time and resources for minimally invasive procedures, that necessitate needle insertion (to name a few; PNB, PICC, CVC, Midline, …).

Product Details:

• Model: Double Head Convex & Mini Linear Color Doppler SIFULTRAS-5.46.
• Screen: Smartphone or tablet screen.
• Supporting system: Apple IOS & Android. Tablet or Smartphone. (Windows system coming soon).
• Display mode: B, B/B, B/M.
• Image grayscale: 256 level.
• Pseudocolor: 8 kinds.
• Image Storage: powerful expansion functions on the application, communication, printing, and storage devices used by customers (mobile phones, Tablet PC).
• Measure: distance, area, obstetrics, and others.
• Power:  built-in battery.
• Power consumption: 10W (unfreeze) /4W (freeze).
• Battery hold-up time: 3 hours.
• Dimension: 156mmx60mmx20mm.
• Size: 104mm*50mm*22mm.
• Weight: 308 grams.
• WiFi type: 802.11g/20MHZ/2.4G.
• Software Supply System: Apple IOS & Android.
• Image Frame Rate: 12f/s.

Features:

• The Double head MLCCD-3.2 is suitable for more than one application at the same time.
• Built-in needle guide.
• Lower cost than buying two separate single-headed probes.
• It can be connected to a Tablet or/and Smartphone.
• Built-in and replaceable battery.
• Advanced digital imaging technology, clear image.
• High cost-effectiveness.
• Wireless connectivity, easy to operate.
• Small and light, easy to carry.
• Useful in emergency, clinics, indoor, outdoor, vet inspections, gynecology, oncology, cardiovascular and abdominal ultrasound scanning, and personal use.
• The intelligent terminal platform, powerful expansion functions on the application, storage, communication, and printing.
• Measures distance, area,  obstetrics.

Specifications:



Convex Side:

• Frequency: 3.5 MHz – 5 MHz.
•  Convex.
• 128 Elements.
• Depth: 100mm ~ 200mm, Adjustable.
• Screen: Smartphone or tablet screen
• Display mode: B, B/B, B/M.
• Image grayscale: 256 level.
• Pseudocolor: 8 kinds.
• Image Storage: Intelligent terminal platform, powerful expansion functions on the application, communication, printing, and storage devices used by customers (mobile phones, Tablet PC).
• – Measure: distance, area, obstetrics, and others.
• Power: built-in battery.
• Power consumption: 10W (unfreeze) /4W (freeze).
• Battery hold-up time: 3 hours.
• WiFi type: 802.11g/20MHZ/2.4G.
• Software Supply System: Apple iOS & Android.
• Image Frame Rate: 12f/s.

Mini Linear Side:

• Frequency : 10MHz / 12MHz / 14MHz.
• Mini Linear.
• 128 Elements.
• Depth: 20 mm ~ 55 mm, Adjustable.
• Field of view(convex array): 80 degrees.
• Screen: Smartphone or tablet screen.
• Display mode: B.
• Image grayscale: 256 level.
• Image Storage: powerful expansion functions on the application, communication, printing, and storage devices used by customers (mobile phones, Tablet PC).
• Suitable for obstetrics, abdomen organs ultrasound scanning.
• Power: built-in battery.
• Power consumption: 10W (unfreeze) /4W (freeze).
• Battery hold-up time: 3 hours.
• WiFi type: 802.11g/20MHZ/2.4G.
• Software Supply System: Apple IOS & Android.
• Image Frame Rate: 12f/s.

Inside the Box: * Double Head Convex & Mini Linear Color Doppler MLCCD-3.2

                           * Wireless Charger

                           * 15-month warranty
